压缩空气自动排水器的应用经验

一．电子自动排水器的原理是：计时器通过控制电磁阀的得电时机间接控制阀门的开启与闭合。

1、 The principle of the electronic automatic drainer is: the timer indirectly controls the opening and closing of the valve by controlling the power on time of the solenoid valve.

空压机系统用户或者服务商可以通过设置计时器上面的开关调节自动排水开启的时长和间隔周期。

Users or service providers of air compressor system can set the switch on the timer to adjust the opening time and interval of automatic drainage.

二．物理自动排水器的原理是：靠排水器里的浮标的浮力来开启排水器。

2、 The principle of the physical automatic drainer is that the drainer is opened by the buoyancy of the buoy in the drainer.

排水器里的液面上升，浮标上升，阀门就会自动开启。冷凝液拍完之后，浮标恢复原位，阀门自然也随之闭合。

When the liquid level in the drain rises and the buoy rises, the valve will open automatically. After the condensate is taken, the buoy returns to its original position and the valve naturally closes.

三．采用液位控制技术的压缩空气零损耗压缩空气系统冷凝液排水器，是随着其容腔中的液面升高到电容式液位传感器设定的高点时，传感器给出信号，先导气阀吸合，切断先导气路。此时，膜阀片上方的压力释放，通过液体作用于膜阀片下方的压力将膜阀片顶离阀座，内部压力随之将冷凝液通过排放管排出系统之外。

3、 The condensate drainer of compressed air zero loss energy-saving compressed air system with liquid level control technology, when the liquid level in its chamber rises to the high point set by the capacitive liquid level sensor, the sensor gives a signal, the pilot gas valve closes, and the pilot gas path is cut off. At this time, the pressure above the diaphragm valve is released, and the diaphragm valve is pushed away from the valve seat by the pressure under the diaphragm valve by the liquid, and then the condensate is discharged out of the system through the discharge pipe by the internal pressure.

根据我们这么多年服务各类工矿企业用户，接触了N多种自动排水器之后的经验。可以明确地告诉您，选择自动排水器重要一点就是，“三分质量，七分养护。”

According to our experience of serving all kinds of industrial and mining enterprise users for so many years and contacting N kinds of automatic drainer. Can tell you clearly, choose energy-saving automatic drainer important point is, "three points quality, seven points maintenance."

根据不同工况环境所制定的“净化设备维护保养计划”和其执行是否到位，决定了您自动排水器的工作状态，运行效果和使用寿命。

According to the "purification equipment maintenance plan" formulated under different working conditions and whether its implementation is in place, it determines the working state, operation effect and service life of your automatic drainer.

即使质量再好，设计再精巧，材质再耐用的零气耗自动排水器，都会因为压缩空气后处理净化系统冷凝液内的固体杂质和油泥污物，使阀芯活动组件出现粘附卡连而造成排污阀口要么打不开而堵塞，要么闭合不严而露气。

No matter how good the quality is, no matter how exquisite the design is, and no matter how durable the material is, the energy-saving and zero gas consumption automatic drainer will cause the solid impurities and oil sludge in the condensate of the compressed air post-treatment purification system to stick to the movable components of the valve core and cause the blowdown valve opening to be blocked, or the air will be exposed if it is not tightly closed.

所以，适时的根据自身使用情况进行自动排水器清洗，检查，更换零部件等维护保养工作，才能让压缩空气后处理净化系统的自动排水器，发挥出正常功能，及时排出冷凝液，且不造成压缩空气损耗浪费。

Therefore, timely according to their own use of automatic drainer cleaning, inspection, replacement of parts and other maintenance work, in order to make the automatic drainer of energy-saving compressed air after-treatment purification system play a normal function, timely discharge condensate, and do not cause compressed air loss and waste.

另外，如果在安装时，将自动排水器前端加装功能足够强大的过滤装置，也能起到很好的保护作用，以保障自动排水器在相当长的使用时间内保持稳定并延长寿命。

In addition, if the front end of the automatic drainer is equipped with a powerful enough filtering device during installation, it can also play a very good role in protection, so as to ensure that the automatic drainer can remain stable for a long time and prolong its service life.
