干燥机的有何特点？

干燥机械是集干燥、粉碎、筛分于一体的新型连续式干燥设备，山东干燥机械具有设计合理，结构紧凑，使用范围广，可用于颜料、染料、精细化工、农药、肥料、饲料、食品、医药、电子等化工轻工诸行业，含水量高的糊状物料干燥。达到高效快速、节能、小设备大生产，连续化操作的目的。

Drying machinery is a new type of continuous drying equipment which integrates drying, crushing and screening. Shandong drying machinery has reasonable design, compact structure and wide application range. It can be used in pigment, dye, fine chemical industry, pesticide, fertilizer, feed, food, medicine, electronics and other chemical and light industries. It has high water content paste material drying. To achieve the purpose of high efficiency, fast, energy saving, large-scale production of small equipment, continuous operation

热空气由入口管以适宜的喷动速度从干燥机底部进入搅拌粉碎干燥室，对物料产生强烈的剪切、吹浮、旋转作用，于是物料受到离心、剪切、碰撞、摩擦而被微粒化，强化了传质传热。在干燥机底部，较大较湿的颗粒团在搅拌器的作用下被机械破碎，湿含量较低、颗粒度较小的颗粒被旋转气流夹带上升，在上升过程中进一步干燥，由于气固两相作旋转流动，固相惯性大于气相，固气两相间的相对速度较大，强化两相间的传质传热，所以该机生产强度高。

The hot air enters the stirring and crushing drying chamber from the bottom of the dryer at an appropriate spouting speed from the inlet pipe, which exerts strong shearing, blowing and rotating effects on the materials. As a result, the materials are granulated by centrifugation, shearing, collision and friction, thus enhancing mass and heat transfer. At the bottom of the dryer, larger and wetter particles are mechanically broken under the action of the agitator. The particles with lower moisture content and smaller particle size are entrained and lifted by the rotating air flow. During the rising process, the gas-solid two-phase flow is rotating, the inertia of the solid phase is greater than that of the gas phase, and the relative velocity of the solid-gas phase is relatively large, which strengthens the mass transfer and heat transfer between the two phases High strength.

山东干燥机械的特点：

The characteristics of Shandong drying machinery are as follows

无机类：硼酸、碳酸钙、氢氧化物、硫酸铜、氧化铁、碳酸钡、三氧化锑、各种金属氢氧化物、各种重金属盐、合成冰晶石等；

Inorganic: boric acid, calcium carbonate, hydroxide, copper sulfate, iron oxide, barium carbonate, antimony trioxide, various metal hydroxides, various heavy metal salts, synthetic cryolite, etc;

有机物：阿特拉津（农药杀虫剂）、月桂酸隔、苯甲酸、安息香酸、杀菌丹、草酸钠、醋酸纤维素等；

Organic matter: atrazine (pesticide and pesticide), lauric acid, benzoic acid, benzoic acid, fungicide, sodium oxalate, cellulose acetate, etc;

陶瓷：高岭土、三氧化硅、粘土等；

Ceramics: kaolin, silica, clay, etc;

染料类：蒽醌、黑色氧化铁、靛蓝颜料、丁酸、氢氧化钛、硫化锌、各种偶氮染料中间体。

Dyes: anthraquinone, black iron oxide, indigo pigment, butyric acid, titanium hydroxide, zinc sulfide, intermediates of various azo dyes.

食品类：大豆蛋白、胶凝淀粉、酒糟、小麦糖、小麦淀粉等。

Food: soybean protein, gelatinous starch, distiller's grains, wheat sugar, wheat starch, etc.

1、多种加料装置供选择，加料连续稳定，过程中间不会产生架桥现象。

1. A variety of feeding devices for selection, continuous and stable feeding, no bridging phenomenon in the process.

2、干燥机底部设置特殊的冷却装置，避免了物料在底部高温区产生变质现象。

2. A special cooling device is set at the bottom of the dryer to avoid the deterioration of materials in the high temperature area at the bottom.

3、特殊的气压密封装置和轴承冷却装置，有效延长传动部分使用寿命。

3. Special air pressure sealing device and bearing cooling device can effectively prolong the service life of transmission part.

4、特殊的分风装置，降低了设备阻力，并有效提供了干燥器的处理风置。

4. The special air distribution device reduces the resistance of the equipment and effectively provides the treatment air device of the dryer.

5、干燥室装有分级环及旋流片，物料细度和终水份可调。（如碳酸钙终水份可调至≤0.1%）。

5. The drying chamber is equipped with a grading ring and a swirl plate, and the material fineness and final moisture can be adjusted. (if the final moisture content of calcium carbonate can be adjusted to ≤ 0.1%).

6、相对其它干燥方法而言，可有效增加物料比重。

6. Compared with other drying methods, it can effectively increase the specific gravity of materials.

7、干燥室内周向气速高，物料停留时间短，有效防止物料粘壁及热敏性物料变质现象，达到高效、快速、小设备、大生产。

7. The drying chamber has high circumferential gas velocity and short residence time of materials, which can effectively prevent materials from sticking to the wall and deterioration of heat sensitive materials, and achieve high efficiency, fast, small equipment and large-scale production.

8、由于物料受到离心、剪切、碰撞、摩擦而被微粒化呈高度分散状态及气固间的相对速度较大，强化传热传质，使该机生产强度高。

8. Because of the high dispersion of the material and the high relative velocity between gas and solid, the heat and mass transfer are strengthened, which makes the production intensity of the machine high.

9、干燥气体进入干燥机底部，产生强烈的旋转气流，对器壁上物料产生强烈的冲刷带出作用，消除粘壁现象。

9. When the dry gas enters the bottom of the dryer, it produces a strong rotating air flow, which has a strong scouring effect on the materials on the wall of the dryer and eliminates the phenomenon of sticking to the wall.

10、在干燥机底部高温区，热敏性物料不与热表面直接接触，解决了热敏性物料的焦化变色问题。

10. In the high temperature area at the bottom of the dryer, the heat sensitive materials do not contact with the hot surface directly, which solves the problem of coking discoloration of heat sensitive materials.

11、干燥室内置旋流片，以控制物料水分达到极低水平。

11. In order to control the moisture content of the material to a very low level, the rotary flow sheet is placed in the drying chamber.

12、干燥室上部分散器可以控制出口物料的粒度及湿度。

12. The upper part of the dryer can control the particle size and humidity of the outlet materials.

13、干燥强度大，适用膏糊状和滤饼的干燥。

13. It is suitable for drying paste and filter cake.
