工业离心式鼓风机选型需要考虑很多方面的因素

目前离心风机应用于工厂、行业、冶金、化工、纺织、食品等行业。离心式鼓风机主要的应用包括输送气体、排掉废气、输送物料、冷却介质等。设备的选择是离心风机生产流程中关键性的一步,但很多人都不了解应该怎么选。

At present, centrifugal fans are used in factories, environmental protection industry, metallurgy, chemical industry, textile, food and other industries. The main applications of centrifugal blower include conveying gas, discharging waste gas, conveying materials, cooling medium, etc. The selection of equipment is a key step in the production process of centrifugal fan, but many people do not know how to choose.

工业离心式鼓风机选型需要考虑很多方面的因素，

Many factors need to be considered in the selection of industrial centrifugal blower,

其中需要考虑就是要平衡前期安装成本和后期运行成本，这里的安装成本包括了离心风机成本，电机成本，风机安装尺寸等。

The installation cost includes centrifugal fan cost, motor cost, fan installation size and so on.

但是有些系统的系数考虑过大，也是没有必要的。比如说离心风机实际运行压力只有预期压力的50%。导致离心通风机在非常的效率点运行，甚工况点偏离选型点过远而引起电机过载。虽然可以改变风机的转速来解决电机过载问题。却也因此损失了很多风量从而降低了系统的生产能力。

However, it is unnecessary to consider the safety factor of some systems. For example, the actual operating pressure of centrifugal fan is only 50% of the expected pressure. As a result, the centrifugal fan runs at a very high efficiency point, and even the operating point deviates from the selection point too far, resulting in motor overload. Although the fan speed can be changed to solve the problem of motor overload. But it also lost a lot of air volume, which reduced the production capacity of the system.

这种情况下，简单的解决方法是选择大功率电机，但会因此同时增加安装成本以及后期的运营成本。与离心通风机在设计中仅仅考虑增加压力余量，不如结合余量与风机的选型，增大使用压力到风机曲线高点压力范围，使操作压力有较大的余量。

In this case, the simple solution is to choose high-power motor, but it will increase the installation cost and later operation cost. It is better to combine the safety margin with the type selection of the fan and increase the range from the operating pressure to the high point of the fan curve, so that the operating pressure has a larger margin.

如果起初系统设计预留20%的系数被认为是较理想的，那么离心通风机选型应选择风机操作点压力少低于高压力的15%，并同时预留10%的系数。这样就会确保所选择的风机会在运行过程中更接近所需的的工作点。

If it is considered to be ideal to reserve 20% of the safety factor in the initial system design, the selection of centrifugal fan should select that the pressure at the operating point of the fan should be at least 15% lower than that of the high pressure, and a safety factor of 10% should be reserved at the same time. This will ensure that the selected wind turbine is closer to the required operating point during operation.
