空压机噪声的控制方法

空压机噪声的控制主要采用消声器、消声坑道和隔声技术三个方面，我们来分别了解一下吧：

The noise control of air compressor mainly includes muffler, anechoic tunnel and sound insulation technology

安装消声器

Install muffler

主要噪声源是进、排气口，应选用适宜的进排气消声器。空压机进气噪声的频谱呈低频特性，进气消声器应选用抗性结构或以个、抗性为主的阻抗复合式结构。空压机的排气气压大，气流速度高，应在空压机排气口使用小孔消声器。

The main noise source is the intake and exhaust ports, so the appropriate intake and exhaust muffler should be selected. The frequency spectrum of air compressor intake noise is low-frequency, so the intake muffler should choose resistance structure or impedance composite structure with resistance as main component. The exhaust pressure of the air compressor is large and the air flow speed is high, so the small hole muffler should be used at the air compressor outlet.

设置消声坑道

Installation of anechoic tunnels

消声坑道的地下或半地下的坑道，坑道壁用吸声性好的砖砌成。把空压机的进气管和消声坑道连接，使空气通过消声坑道进入空压机。采用消声坑道可使空压机的进气噪声大大降低，使用寿命也比一般消声器长。

The underground or semi underground tunnel of anechoic tunnel. The wall of the tunnel is made of sound-absorbing bricks. Connect the air inlet pipe of the air compressor with the anechoic tunnel, so that the air enters the air compressor through the anechoic tunnel. The use of anechoic tunnel can greatly reduce the intake noise of air compressor and prolong its service life.

建立隔声罩

Set up acoustic enclosure

在空压机的进、排气口安装消声器或设置消声坑道以后，气流噪声可以降到80db(a)以下，但空压机的机械噪声和电机噪声仍然很高，因此还应在空压机的机组上安装隔声罩。4、悬挂空间吸声体：在佛山凌格风空压机站，高大空旷的厂房混响很重。若在厂房顶棚分散悬挂吸声体，厂房的噪声可降低3-10db(a),混响时间降低5-10s

The air flow noise can be reduced to less than 80dB (a) after installing mufflers at the inlet and outlet of the air compressor or setting the noise elimination tunnel. However, the mechanical noise and motor noise of the air compressor are still very high. Therefore, sound insulation cover should be installed on the air compressor unit. 4. Suspended space absorber: in Foshan Lingge air compressor station, the large and open workshop reverberates heavily. If the absorbers are distributed on the roof of the workshop, the noise of the workshop can be reduced by 3-10db (a) and the reverberation time can be reduced by 5-10S
