制氮系统的冷干机室外使用注意事项

1）不要放在日晒、雨淋、风吹或相对湿度大于百分之八十五的场所。不要放置在灰尘多、有腐蚀性或可燃性气体的环境中。不要放置在有振动、冷凝水有冻结危险的地方。不要离壁面太近，以免通风不良。不得已需在有腐蚀性气体的环境中使用，应选用铜管经防锈处理的干燥器或不锈钢热交换器型的干燥器。应在环境温度40度以下使用。

1) Do not put it in the sun, rain, wind or relative humidity greater than 85%. Do not place in dusty, corrosive or combustible gas environment. Do not place in the place where there is vibration and condensation water is in danger of freezing. Don't get too close to the wall to avoid poor ventilation. Must not be used in corrosive gas environment, should choose copper tube antirust treatment dryer or stainless steel heat exchanger type dryer. It should be used under the ambient temperature of 40 ℃.

2）压缩空气的进口不要接错。为便于维修，要确保维修空间，应设置旁通管路。要防止空压机的振动传给干燥器。配管重量不要直接加在干燥器上。

2) Don't connect the inlet of compressed air by mistake. In order to facilitate maintenance and ensure maintenance space, bypass pipeline should be set. To prevent the vibration of the air compressor to the dryer. Piping weight should not be added directly to the dryer.

3）排水管不要向上立着，不要打折或压扁。

3) The drain pipe should not stand upward and should not be bent or flattened.

4）电源电压允许波动小于百分之十。应设置适当容量的漏电断路保护器。使用前必须接地。

4) The allowable fluctuation of power supply voltage is less than 10%. Leakage circuit breakers of suitable capacity shall be provided. It must be grounded before use.

山东制氮机

Shandong nitrogen generator

5）压缩空气进口温度过高、环境温度过高（40度以上）、使用流量超过额定处理空气量、电压波动超过百分之十、通风太差（冬季也要换气，否则室温也会升高）等情况下，保护电路会发挥作用，指示灯灭，停止运转。

5) When the inlet temperature of compressed air is too high, the ambient temperature is too high (above 40 ℃), the flow rate exceeds the rated air handling capacity, the voltage fluctuation exceeds 10%, and the ventilation is too poor (air exchange is necessary in winter, otherwise the room temperature will rise), the protection circuit will play a role, the indicator will go out and stop running.

6）当空气压力高于0.15MPa时，常开式自动排水器的排水口才能关闭。冷干机的排水量太小时，排水口处于开启状态，有空气吹出。

6) When the air pressure is higher than 0.15Mpa, the outlet of the normally open automatic drainer can be closed. When the water displacement of the dryer is too small, the drain is in the open state and there is air blowing out.

7）压缩空气质量差，如混入灰尘和油分，这些赃物会粘附在热交换器上，降低其工作效率，同时排水也易失效。希望在干燥器进口设置过滤器，并要确认一天排水不少于一次。

7) The quality of compressed air is poor, such as mixed with dust and oil, which will adhere to the heat exchanger, reduce its working efficiency, and drain water is easy to fail. It is hoped that a filter should be set at the inlet of the dryer, and the drainage should not be less than once a day.

8）干燥器的通风口每月要用吸尘器清扫一次。

8) The air vent of dryer should be cleaned with vacuum cleaner once a month.

9）接通电源，待运转状态稳定后，再接通压缩空气。停止运转后，必须等待3min以上才能再起动。

9) Turn on the power supply, and then turn on the compressed air when the running state is stable. After stopping operation, it must wait for more than 3 minutes to restart.

10）若使用自动排水器，应经常检查其排水功能是否正常。要经常清扫冷凝器上的灰尘等。要经常检查冷媒的压力，可判断冷媒是否泄漏及冷冻机的能力是否有变化。要检查排除冷凝水的温度是否正常。

10) If automatic drainer is used, its drainage function should be checked regularly. Always clean the dust on the condenser. Check the pressure of the refrigerant frequently to judge whether the refrigerant leaks and whether the capacity of the refrigerator changes. Check whether the temperature of condensate water is normal.
