自动排水器的安装步骤你需要了解一下！

相信大家都见过自动排水器在我们生活周边的应用，自动排水器用于自动排除管道低处、油水分离器、气罐及各种过滤器底部等处的冷凝水。可安装于不便进行人工排污水的地方，如高处、低处、狭窄处。并可避免人工排水被遗忘而造成压缩空气被冷凝水重新污染。接下来让我们一起学习一下关于山东自动排水器的安装步骤。希望能够帮助到有这方面需求的朋友们！

I believe you have seen the application of automatic drainer in our living surroundings. Automatic drainer is used to automatically drain the condensate water at the bottom of pipes, oil-water separators, gas tanks and various filters. It can be installed in places where it is inconvenient to discharge sewage manually, such as high, low and narrow places. And it can avoid the artificial drainage being forgotten and causing the compressed air to be re polluted by the condensed water. Next, let's learn about the installation steps of automatic drainer. Hope to be able to help friends with this demand!

一：在你开始安装之前应该要做的事是把清洁压缩空气系统里打扫干净，这一步做好了对于我们后面的安装有很大的帮助。

1： Before you start the installation, what you should do is to clean the compressed air system. This step is very helpful for our later installation.

二：在你安装的时候应该注意机器上阀体上面箭头的具体指向，还有出水口千万不要用不抗气流冲击的软管来连接，不让你当你安装完成开始使用一段时间以后你就会发现你的水排不出去了，此时应该就是这个软管脱离了。

2： When you install, you should pay attention to the specific direction of the arrow on the valve body of the machine, and the water outlet. Do not use the hose that is not resistant to the impact of air flow to connect it. When you finish the installation and start to use it for a period of time, you will find that your water can not be discharged. At this time, the hose should be separated.

三：注意你接入自动排水器的电压大小应该与自动排水器上的额定电压一样，大概也行，但是不能太低也不能高于，最多就是小于等于了。而且如果你使用直流电的话，那你接入的正极必须得与自动排水器上的接头“1”连接。

3： Note that the voltage you connect to the automatic drainer should be the same as the rated voltage on the automatic drainer, probably OK, but not too low or higher, at most less than or equal to. And if you use direct current, the positive pole you connect must be connected to the connector "1" on the automatic drainer.

四：如果是出厂的时候就已经接好的排水阀门的话，那我们我们就应该要明白的是此时自动排水器上的褐色导线为火线L，蓝色导线为零线N，黄绿双色的是需要我们完成安装后连接的地线GND。

4： If the drain valve has been connected before leaving the factory, what we should understand is that the brown wire on the automatic drain device is the live wire L, the blue wire is the zero wire n, and the yellow and green wire is the ground wire GND that we need to connect after installation.

五：为了避免接线盒上的长螺钉进水烧毁，我们必须得把长螺钉好好拧紧。这里给点自动排水器安装小提示，安装前电源必须为断开状态，还有就是压缩空气得保证完全排空即此时自动排水器中属于零压力状态下。

5： In order to prevent the long screws on the junction box from being burnt out by water, we must tighten them well. Here are some tips for the installation of automatic drainer. Before the installation, the power supply must be disconnected, and the compressed air must be fully drained, that is, the automatic drainer is in the zero pressure state.

其实它的安装方法并不是特别难，主要在于安装之前了解关于安装它的一些常识就好，知道了这些小常识后我相信自动排水器的安装已不再是那么的难了，不过鉴于安全以及使用寿命的问题，。

In fact, its installation method is not particularly difficult. The main thing is to know some common sense about installing it before installation. After knowing these common sense, I believe that the installation of automatic drainer is no longer so difficult, but in view of the safety and service life problems,.
